Description:
DESCRIPTION
for cutting in vertical and horizontal position. Heavy duty machine assuring strength with a welded steel frame.
Automatic shifting frame to avoid the cutting of the plastic strips during the horizontal cuts.
Bottom aluminium supports with phenolic soles, for a safe support of the panels, and with Lift-up Rollers for a better sliding of the same.
Manual displacement of the beam and saw carriage for horizontal and vertical cuttings; these last are assured in N5 fixed points locking to the frame.
Manual plunging and returning of saw carriage, by means of ergonomic lever.
-Automatic shifting frame: ELECTRIC.
-N° 4 positioners for horizontal cuttings.
-N° 2 Stops for vertical cuttings.
-Short piece cutting device (L. 2340 mm). to support small panels.
-Lift-up rollers.
-SELF-BRAKING motor.
-V.400/3/50Hz.
-Integrated dust exhauster with bag or pre-arranged for independent dust extraction (to be specified on order)
-All standard accessories: safety device, soundproofing, set service tools, user’s manual.
